U5310A 10-bit ADC Card

from 5 GS/s to 10 GS/s (Discontinued)

This product has been discontinued.

Please contact Solutions@acqiris.com to get information about replacement alternatives.

Key features

  • 10-bit resolution
  • 1 channel with up to 10 GS/s sampling rate with interleaving enabled
  • 2 channels up to 5 GS/s simultaneously sampling
  • DC up to 2.5 GHz bandwidth
  • 50 Ω input impedance, DC coupled
  • Selectable 250 mV or 1 V full scale range (FSR)
  • 15 ps RMS trigger time interpolator (TTI) precision
  • Low noise density and low distortion
  • Optimized frequency response flatness
  • Excellent and flat SFDR over a large analysis bandwidth (> 56 dBc typical)
  • Up to 4 GB DDR3 on-board memory
  • On-board data processing unit using a Xilinx FPGA



Customer values

  • Fast PCIe 10-bit digitizer with on-board real-time processing
  • Capture wide bandwidth signals
  • High dynamic range acquisition for better measurement fidelity
  • Accurate measurement
  • Capable of switching between multiple firmware programs

Select the document from the list and click on the button to download it.

download

Real-time proccessing

At the heart of the ADC card, the FPGA enables real-time signal processing. The following firmware options are available:

  • The interleaved option (-INT) that enables up to 10 GS/s on one channel, doubling the sampling rate while maintaining the same signal integrity high performances
  • The average option (-AVG) that allows accumulation of waveforms from 1 to 16k triggers on dual synchronous channels at up to 5 GS/s, or on single channel at 10 GS/s. An innovative programmable trigger output can be used to optimize the signal-to-noise ratio (SNR) and increase the ability to isolate very small peaks from the signal noise
  • The continuous simultaneous acquisition and readout with triggers (-CST) option that supports multiple triggered record acquisitions and simultaneous output data streaming.

Block Diagram

Key specifications & Variants

U5310AU5310A-INT
Channel (s)2 channels1 or 2 channels
Max. Sampling rateUp to 5S/s on 2 channels
up to 5 GS/s on 2 channels
or up to 10 GS/s on 1 channel (INT)
BandwidthDC to 2.5 GHzDC to 2.5 GHz
Resolution10-bit10-bit
Memoryup to 4 GBup to 4 GB
Input Full scale range250 mV or 1 V
Selectable by SW		250 mV or 1 V
Selectable by SW
Form factorPCIe CardPCIe Card
InterfacePCIe gen2PCIe gen2
Max. Data transfer rate2.5 GB/s2.5 GB/s

Select the card or module on the list to download the Datasheet.:

Software

The U5310A come with associated Software Development Kit (Windows or Linux).

It includes a graphical user interface (Soft Front Panel) to capture and display the acquired data in time or frequency domain.
