OEM Partnership

We are dedicated to enhancing our customer’s success with our ability to support them on a daily and long-term basis.

Contact Us

Acqiris develops high-quality, high-speed signal acquisition products, delivering technical excellence to your unique application. We assist you from the earliest stages of system development and throughout your product’s life cycle. Founded in 1998, Acqiris joined Agilent in 2006 and continued to operate as the electronic measurement portfolio of Keysight Technologies (2014).

On August 1, 2017, we became a new company and returned to our original name, Acqiris. You will be able to trust on Acqiris as a strong strategic partner in the development, manufacturing and support of responsive signal acquisition components for OEMs as well as for future enhancements and specific developments. Because each OEM project is unique, understanding your constraints guarantees that the technical solution we develop fits your actual needs and is driven by innovation. We trust in synergy and greatly value the relationship we build with our partners.

Trust in Synergy

Partner from the earliest phases of development.

Bring technical excellence to your unique application.

Minimize risk and total-cost of ownership.

Synergy builds a lasting relationship of trust in the solutions we deliver.

Products

High-Speed ADC Cards with FPGA Real-Time Processing

SA2 14-bit ADC Card family, from 1 GS/s up to 8 GS/s, with FPGA real-time signal processing
SA2 14-bit ADC Card family, from 1 GS/s up to 8 GS/s, with FPGA real-time signal processing

The new SA2 platform is especially optimized for OEM requirements and leverages Acqiris’ new high-performance 14-bit ADC card generation which performs fast signal acquisitions with excellent signal fidelity across a wide bandwidth.

  • sampling rate from 1 GS/s to 8 GS/s
  • 1 or 2 channels
  • Bandwidth up to 2.5 GHz
  • Real-time processing in the FPGA
  • Low noise density and low distortion
  • Optimized frequency response flatness

Overall performance of the SA2 enables deeper, faster and more accurate measurement and analysis, allowing our customers to design breakthrough products.

Learn more about SA2 14-bit ADC cards / digitizers.

Key Features & Applications

Accurate and precise measurement

  • 14-bit resolution
  • 1 or 2 channels simultaneously sampling
  • Sampling rate versions: from 1 GS/s to 8 GS/s
  • 950 MHz and up to 2.5 GHz bandwidth
  • DC coupled, 50 Ohm input impedance
  • Selectable full scale range: 500 mV or 2.5 V (FSR)
  • Programmable DC offset (± FSR/2)

Signal fidelity

  • Low noise density and low distortion
  • Optimized frequency response flatness
  • Excellent and flat SFDR over a large analysis bandwidth (70 dBc)
  • hundred picoseconds pulse analysis.
  • Unique 15 ps RMS trigger time interpolator precision.

Applications

  • Analytical Mass Spectrometry time-of-flight (TOF)
  • Medical research and imaging instrumentation (e.g. SS-OCT)
  • Environmental monitoring using laser scanning (LiDAR)
  • Distributed strain and temperature sensors (DSTS)
  • Ultrasonic non-destructive testing (SAM)
  • Acqiris offers also many other solutions
U5303A PCIe High-Speed Digitizer - ADC Card, 12-bit, from 500 MS/s to 4 GS/s, FPGA signal processing
U5303A PCIe High-Speed Digitizer - ADC Card, 12-bit, from 500 MS/s to 4 GS/s, FPGA signal processing

The U5303A is a two channel PCIe 12-bit signal acquisition card with programmable on-board processing. This ADC card occupies a single full-length PCIe slot of the host PC and captures signals on 2 channels, from DC to 2 GHz at 1 GS/s, 1.6 GS/s or 2 GS/s. Featuring DDR3 acquisition memory up to 4 GB, this digitizer includes a Xilinx FPGA allowing the implementation of custom real-time processing algorithms. ...

The U5303A ADC card provides several firmware options:

  • The digitizer firmware option (-DGT) with up to 2 GS/s, 1.6 GS/s, 1 GS/s or 500 MS/s per channel, included in most configurations
  • The interleaved option (-INT) that allows two channels to be combined to reach 4 GS/s, 3.2 GS/s or 2 GS/s in one channel acquisition mode
  • The real-time sampling and averaging option (-AVG) that performs waveform accumulations at up to 4 GS/s on single-channel and 2 GS/s on dual-channel
  • The real-time signal peak detection option (-PKD) that performs peak detection and enables generation of a histogram of peak versus time for successive acquisitions
  • The simultaneous acquisition and readout option that enables longer acquisition time, allowing to acquire signals while reading out the previously acquired data, either continuously (-CSR) or using triggered multi-records (-TSR)

Besides, this ADC card offers the following application options:

  • The swept source OCT options that enables real-time OCT signal processing and supports A-scan rate from 50 kHz to 100 kHz (-SS1) or A-scan rate of 200 kHz (-SS2) – contact us for faster rate.

Let our ADC card specialists help you find the best solution for your applications. Contact us. Access to technical documents or download Datasheet.

Datasheet

Applications & Key Features

Applications

  • Medical research instrumentation (e.g. OCT) and analytical time-of-flight (MS-TOF)
  • Environmental monitoring (LiDAR), ultrasonic non-destructive testing (NDT)
  • Astronomy, physics

Functionality

  • 1 channel with 12-bit resolution at up to 4 GS/s sampling rate in interleaved mode
  • 2 channels at up to 2 GS/s simultaneous sampling rate
  • DC up to 2 GHz bandwidth
  • Dedicated firmware options and application options

Document Library

Acqiris continues to manufacture and support the U5203A 12-bit high-speed digitizer.

U5310A PCIe High-Speed Digitizer - ADC Card, 10-bit, from 5 GS/s to 10 GS/s, FPGA signal processing
U5310A PCIe High-Speed Digitizer - ADC Card, 10-bit, from 5 GS/s to 10 GS/s, FPGA signal processing

The U5310A is a two channel PCIe, DC coupled 10-bit signal acquisition card providing sample rates up to 10 GS/s with 2.5 GHz bandwidth for use in a variety of advanced imaging and processing systems. Featuring unique spurious-free dynamic range (SFDR) and signal-to-noise ratio (SNR) performances in high frequencies, especially at 250 mV full scale range (FSR), the U5310A ADC card is suited for embedded OEM applications requiring signal acquisition at wide bandwidth and high dynamic range.

At the heart of the ADC card, the FPGA enables real-time signal processing. The following firmware options are available:

  • The real-time averaging option (-AVG)
  • The continuous simultaneous acquisition and readout with triggers (-CST) option

Learn more about U5310A ADC cards / digitizers.

Or let our ADC card specialists help you find the best solution for your applications. Contact us.

The U5303A ADC card provides several firmware options:

  • The digitizer firmware option (-DGT) with up to 2 GS/s, 1.6 GS/s, 1 GS/s or 500 MS/s per channel, included in most configurations
  • The interleaved option (-INT) that allows two channels to be combined to reach 4 GS/s, 3.2 GS/s or 2 GS/s in one channel acquisition mode
  • The real-time sampling and averaging option (-AVG) that performs waveform accumulations at up to 4 GS/s on single-channel and 2 GS/s on dual-channel
  • The real-time signal peak detection option (-PKD) that performs peak detection and enables generation of a histogram of peak versus time for successive acquisitions
  • The simultaneous acquisition and readout option that enables longer acquisition time, allowing to acquire signals while reading out the previously acquired data, either continuously (-CSR) or using triggered multi-records (-TSR)

Besides, this ADC card offers the following application options:

  • The swept source OCT options that enables real-time OCT signal processing and supports A-scan rate from 50 kHz to 100 kHz (-SS1) or A-scan rate of 200 kHz (-SS2) – contact us for faster rate.

Let our ADC card specialists help you find the best solution for your applications. Contact us. Access to technical documents or download Datasheet.

Datasheet

Applications & Key Features

Applications

  • Analytical time-of-flight (MS-TOF)
  • Environmental monitoring (LiDAR)
  • Ultrasonic non-destructive testing (NDT), distributed strain and temperature sensors (DSTS)
  • Medical research instrumentation

Functionality

  • 2 channels with 10-bit resolution simultaneously sampling at up to 5 GS/s
  • 1 channel at 10 GS/s with interleaving enabled
  • DC up to 2.5 GHz analog bandwidth and large acquisition memory up to 4 GB
  • Low distortion and optimized frequency response flatness.

Document Library

U5309A PCIe High-Speed Digitizer - ADC Card, 8-bit, from 500 MS/s to 2 GS/s, FPGA signal processing
U5309A PCIe High-Speed Digitizer - ADC Card, 8-bit, from 500 MS/s to 2 GS/s, FPGA signal processing

U5309A and SA1 high-speed ADC cards / digitizers,
8-bit from 500 MS/s to 2 GS/s, with FPGA processing

• 8-bit resolution
• 1 or 2 channels sampling simultaneously at 500 MS/s, 1 GS/s or 2 GS/s
• Bandwidth from DC up to 500 MHz
• PCIe form factor, occupying a single full-length PCIe slot of the host computer
• proprietary low noise front-end
• FPGA for real-time processing algorithms
• Optional low voltage range version (LVR) dedicated to small signals
Suited for OEM’s applications requiring a reliable, stable and cost effective signal acquisition solution.
Learn More

The U5303A ADC card provides several firmware options:

  • The digitizer firmware option (-DGT) with up to 2 GS/s, 1.6 GS/s, 1 GS/s or 500 MS/s per channel, included in most configurations
  • The interleaved option (-INT) that allows two channels to be combined to reach 4 GS/s, 3.2 GS/s or 2 GS/s in one channel acquisition mode
  • The real-time sampling and averaging option (-AVG) that performs waveform accumulations at up to 4 GS/s on single-channel and 2 GS/s on dual-channel
  • The real-time signal peak detection option (-PKD) that performs peak detection and enables generation of a histogram of peak versus time for successive acquisitions
  • The simultaneous acquisition and readout option that enables longer acquisition time, allowing to acquire signals while reading out the previously acquired data, either continuously (-CSR) or using triggered multi-records (-TSR)

Besides, this ADC card offers the following application options:

  • The swept source OCT options that enables real-time OCT signal processing and supports A-scan rate from 50 kHz to 100 kHz (-SS1) or A-scan rate of 200 kHz (-SS2) – contact us for faster rate.

Let our ADC card specialists help you find the best solution for your applications. Contact us. Access to technical documents or download Datasheet.

Applications & Key Features

Applications

  • Analytical time-of-flight (MS-TOF)
  • Fiber sensing (DSTS / DAS)
  • Laser ranging / Emission monitoring
  • Ultrasonic imaging, Advanced research experiments

Functionality

  • 1 or 2 channels at up to 2 GS/s
  • 8-bit resolution and a DC to 500 MHz frequency range
  • Up to 4 GB DDR3 on-board memory and acquisition control using a Xilinx FPGA
  • Dedicated firmware options and application options

Document Library

Acqiris continues to manufacture and support the U1084A 8-bit high-speed digitizer.

" We look forward to joining forces with you
to develop and deliver the critical ADC technology
you need for your applications. "
